规格 EATV
颜色 RED
型号 PHYES-EATV011
CONTACT ONLINE
Parameters
规格
EATV
颜色
RED
型号
PHYES-EATV011
I know
Detail
Motor48V/1000W
Controller48V/1000W
Chain wheel25H9/80
Chain25H86knots
Front wheel(with inner tire)14*4.10-6
Rear wheel(with inner tire)14*5.00-6
Battery12v12ah *3PCS
BrakeFront Disc brake120#,Rear Disc Brake140#
Seat higher540mm
Gear1/2/3+Reverse+speedGear1-15km/h,Gear2-20km/h,Gear3-30km/h
Runing time55mins
Loading weight54kgs
N.W60kgs
G.W62kgs
Alex distance720mm
Front wheel distance585mm
Rear wheel distance455mm
Product size1130*700*760mm
Package size1160*570*510mm
Package styleiron frame +carton
Color availablePink,Green,Blue,Orange,Red,Yellow
RemoteNO,optional
Container capacity20GP:80PCS; 40HQ:200PCS
