规格 36V 12AH LEAD-AICD ELECTRIC ATV
颜色 Muti-colours
型号 ELECTRIC ATV
CONTACT ONLINE
Detail
BATTERY36V/12AH
MOTOR36V/1000W
RATED SPEED2800±100
RATED POWER1000W±10%
CONTROLLER36V/1000W
CHARGINGAC80-240V   50-60Hz   36V/MAX1.6A
CHARGING TIME（H）8-9
MAX SPEED (km/h)22
MAX LOAD（Kg）50
MAX CLIMBLING（°）≦10
MAX RANGE（Km）20
SEAT HEIGHT（mm）500
BRAKEFRONT DISC/φ120；REAR DISC/ φ140
TIRE SIZEFRONT.REAR：4.10-4
N.W/G.W（kg）40/50
PRODUCT SIZE（mm）1000×590×600
PACKING （mm）995×580×430
TRANSMISSIONCHAIN
QTY110Pcs/20'FT,230Pcs/40'GP,275Pcs/40'HQ
PACKING（mm）IRON（980*560*430）+CARTON(5LAYER)
