PHYES-EATV004
Detail
| Motor | front 60V 2000W Brushless DC and rear 60V 2000W Brushless DC |
| Battery Spec. | 5pcs x 12V 50Ah lead acid |
| Charger | 80-240V/50-60Hz 7A |
| Charge period | 8-10 hours |
| Battery-life | 300 cycles |
| Max torque(N·M) | 94 |
| Max speed | 50km/h（4WD） 44Km/h (2WD) |
| Max distance range | 50km |
| Max climbing angle | 45 |
| Load capacity | ≤150kg |
| Rim | Aluminum |
| Wheelbase | 1250mm |
| Head light | 12V35W |
| Brake system | front/rear disc |
| Brake | front/manual, rear/manual |
| Transmission | shaft driving |
| Suspension | hydraulic suspension |
| G.W/N.W | 270kgs / 244kgs |
| Carton size | 1580×1060×760mm |
| Product size | 1830×1100×1100mm |
| Tyre size | Front 23*7-10 ,Rear 22*10.0-10 |
| Qty | 20pcs/20', 42pcs/40', 42pcs/40HQ |
| Colour | Red, Blue, Green, Black,etc |
