PHYES-ATV020

share
WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
规格 110CC 125CC
颜色 Muti-colours
型号 110CC 125CC ATV
CONTACT ONLINE
Detail
Engine
50cc-110cc, air cooled, single cylinder,4-stroke,automatic clutch
Drive Train
Chain Drive
Start Mode
Electric Start
Battery
12V 5AH
Suspension
Spring suspension
Braking Method
Front drum brake/Rear disc brake
Tire
16*8-7
Mini Ground Clearance
85mm
Rated Loading Capacity
100kg
Wheelbase
850mm
Tread
Front wheel : 630mm; Rear wheel: 590mm
Max Speed
≤61km/h
Tank Capacity
3.5L
Bore*Stroke
52.4*49.5mm
Rated. Power
5.5Kw at 8000r/min
Max Torque
7.2N.m at 5500r/min
N.W
98 kgs
Dimension (L*W*H)

1380mm x 840mm x 860mm
Packing Size(L*W*H)

1260mm x 760mm x 650mm
