规格 60V 5000W 2WD ATV
颜色 Muti-colours
型号 ELECTRIC ATV
CONTACT ONLINE
Detail
Motor:60V5000W brushless differential speed motor AC, 60V5000W controller
Battery:5pcs x 12V 50Ah lead acid
Charger: 110-240V/50-60Hz   7A
Charge period: 8-10 hours
Battery-life: 300 cycles
Chassis:Load capacity: ≤200kgs
Rim:Aluminum
Brake system: front/rear disc
Brake: front/manual, rear/manual
Suspension: hydraulic suspension
Transmission: shaft driving
Tyre size: F/23*7-10 R/22*10.00-10,Aluminum Hub
Dimensions:

Front&RearWheel base:1150mm Front wheel base: 880mm

Rear wheel base: 900mm

Ground clearance：172mm   Seat height:820mm
Product size : 1920*1150*1150mm
Carton size: 1960*1120*780mm
G.W/N.W: 265/291kgs
Other:

Max speed: 47Km/h (5000W)

Max distance range: 50km

Max climbing angle: 45/5000W

color:Red, Blue, Green, Black,camo etc
container:Qty: 12pcs/20', 20pcs/40', 30pcs/40HQ
Using age16+ year olds
