EGK03 | Motor: | 60V20ah1200W AC brushless differential motor DC |
Battery: | battery: 60V20AH lead-acid battery | |
charger: 80-240V 50-60Hz /2.5A | ||
Charge period: duration of charging 6-8 hours | ||
Battery-life: 300 cycles | ||
Chassis: | Load capacity: ≤160kgs | |
Rim:iron | ||
Brake system: rear hydraulic disc brake | ||
Transmission: shaft driving | ||
Tyre size: Front /,Rear 16*8-7,black iron rim | ||
Dimensions: | Front Wheelbase: 1010mm back wheelbase :1020mm Ground clearance:100mm | |
Product size :1985*1275*880mm | ||
Carton size:183*118*73CM (disassemble wheels:175*107*63cm) | ||
N.W/G.W: 153/173kgs | ||
Other: | 3speed: 6/20/37km/h Max distance range: 35kms Max climbing angle: 35 | |
color: | Red, Blue, Black,Camo,etc | |
container: | Qty:18pcs/20', 52pcs/40HQ | |
Using age: | 7+ year olds | |
Advantages: | 1. with the easy removable batteries ,and LED power meter 2. with the adjusted 2seat, used for different age driver 3. with 3 different speed available, 0-6km/h, 7-20km/h, 20-37km/h. and reverse 4.with front and back fenders 5.with front and back turn lights |
Yongkang PHYES vehicle Co.,Ltd
