规格 ATV
颜色 RED
型号 PHYES-ATV005
CONTACT ONLINE
Detail
Engine
50cc-110cc, air cooled, single cylinder,4-stroke,automatic clutch
Drive Train
Chain Drive
Start Mode
Electric Start
Battery
12V 5AH
Suspension
Spring suspension
Braking Method
Front drum brake/Rear disc brake
Tire
16*8-7
Mini Ground Clearance
85mm
Rated Loading Capacity
100kg
Wheelbase
850mm
Tread
Front wheel : 630mm; Rear wheel: 590mm
Max Speed
≤61km/h
Tank Capacity
1.2L
Bore*Stroke
52.4*49.5mm
Rated. Power
5.5Kw at 8000r/min
Max Torque
7.2N.m at 5500r/min
N.W
96 kgs
Dimension (L*W*H)
1330mm*790mm*1105mm
Packing Size(L*W*H)
1300mm*770mm*650mm
