PHYES-EDB03

PHYES-EDB03

SPECIFICTION

Wheelbase

1190±10mm

Front inclination angle

23degrees

Minimum ground clearance

180mm

Seat height

870mm±5mm

Overall dimensions

1760mmx780mmx1160 mm

Handle width

780mm aluminum silver

Motor power

72V3000W

Battery

72V30A/Li

Gears

1-2-3/reverse/P/S

transmission

chain transmission

Maximum speed

75 km/h

Charging time

5-8 hours

Vehicle weight

90kg

Max loading

120 kg

Tire Assembly Specifications

Front 17 Rear 14

Shock absorber

inverted hydraulic shock absorber/silver cylinder black foot

Rear reduction: built-in hydraulic shock absorber/white spring black seat

Braking method:

Front and rear disc brakes (front: handbrake, rear: foot brake)

Vehicle frame

The welding color of high-strength steel pipes for the frame is optional

Flat fork straight steel silver

straight steel silver

Throttle lever off-road state

off-road state

Colour

black/red/blue/green/orange/white

motor

Transmission center motor

Climbing ability

30 degrees
